Pentair MasterTemp Heater Replacement Parts

Pentair

Pentair MasterTemp Heater Replacement Parts

Fits models:MasterTemp 175MasterTemp 200MasterTemp 250MasterTemp 300MasterTemp 400MasterTemp HD

  • Genuine PentairOEM factory parts
  • Fast ShippingFrom AZ & NV
  • 5 Local StoresPhoenix · Las Vegas
  • Expert HelpReal pool pros
Shop the complete heater

Exploded View

Tap a number to see the part, price and stock.

Pentair Pentair MasterTemp Heater Replacement Parts exploded parts diagram

Pick a part

Click any number on the diagram, or choose from the parts list below.

Know the part number? Use the search in the list.

Common Problems

Show the parts that usually fix it.

Replacement Parts (22)

Coil/Tubesheet Sealing O-Ring Kit

Part # 77707-0117 / 460749 / 77707-0118 / 77707-0119

Call for availability

O-Ring

Part # U9-226Z

Call for availability

Drain Plug

Part # U178-920PZ

$8.94$14.99In Stock

Pressure Relief Valve

Part # 473715Z

Call for availability

2 in. Union Adapter Package (Includes 2)

Part # Call for part number

Call for availability

Pro Service Package - Water Parts (Includes items in a reusable hard case, 8, 9, 15, not s

Part # 461102

Call for availability

Accessories and Documents Bundle

Part # 462051

Call for availability

INSRT MFLD MASTERTEMP ASME ANTIRODENT

Part # 462038Z

Call for availability

3/4 in. Union

Part # 38404-4097S

Call for availability

Air Blower Kit

Part # 77707-0250 / 77707-0251 / 460743 / 460757 / 77707-0253 / 77707-0254 / 460744 / 460758 / 77707-0256

Call for availability

Item #6 included in Item #7

Part # Call for part number

Call for availability

Air Orifice Kit

Part # 460798 / 77707-0111 / 460745 / 460759 / 77707-0113

Call for availability

One Piece Metal Chamber/ Combustion Chamber Assembly

Part # 474957

Call for availability

One Piece Metal Elbow/ Combustion Chamber Cover Assembly

Part # 474958

Call for availability

Tub O-Ring Kit

Part # 474952

Call for availability

Metal Vent Cover

Part # 42002-0005S

Call for availability

Heater Top

Part # 42002-0034Z

Call for availability

Side Panel (Service Panel) with 4 clips and 4 screws

Part # 42002-0039Z

Call for availability

Side Panel (Manifold)

Part # 42002-0033Z

Call for availability

Heater Bottom

Part # 42002-0031Z

Call for availability

Side Panel (Flue Stack)

Part # 42002-0032Z

Call for availability

J Box Cover

Part # 42002-0041Z

Call for availability

11 ea screws, 11 ea clips and 8 wing-nuts

Part # 474292

Call for availability

INSRT MFLD MasterTemp ASME Antirodent

Part # 462038

Call for availability

Gas Orifice Kit - NG

Part # 461002

Call for availability

Gas Orifice Kit - NG

Part # 77707-0431

Call for availability

Gas Orifice Kit - NG

Part # 460739

Call for availability

Gas Orifice Kit - NG

Part # 460753

Call for availability

Gas Orifice Kit - NG

Part # 77707-0411

Call for availability

Gas Orifice Kit – Propane

Part # 460797

Call for availability

Gas Orifice Kit – Propane

Part # 77707-0461

Call for availability

Gas Orifice Kit – Propane

Part # 460740

Call for availability

Gas Orifice Kit – Propane

Part # 460754

Call for availability

Gas Orifice Kit – Propane

Part # 77707-0441

Call for availability

NG to Propane Conversion Kit

Part # 460794

Call for availability

NG to Propane Conversion Kit

Part # 77707-1461

Call for availability

NG to Propane Conversion Kit

Part # 460741

Call for availability

NG to Propane Conversion Kit

Part # 460755

Call for availability

Propane to NG Conversion Kit

Part # 460795

Call for availability

Propane to NG Conversion Kit

Part # 77707-1431

Call for availability

Propane to NG Conversion Kit

Part # 460742

Call for availability

Propane to NG Conversion Kit

Part # 460756

Call for availability

Blower/Adapter Plate Gasket Kit (Includes Item Nos. 8, 9, 10, 12)

Part # 77707-0011

Call for availability

Flameholder Kit

Part # 77707-0202

Call for availability

Flameholder Kit

Part # 460746

Call for availability

Flameholder Kit

Part # 77707-0203

Call for availability

Flameholder Kit

Part # 77707-0204

Call for availability

Insulation Kit (Includes Item Nos. 13, 14, 16, 17, 18, 19)

Part # 77707-0008

Call for availability

Lower Enclosure Insulation

Part # 42001-0074S

Call for availability

Metal Vent Cover Assembly

Part # 42001-0214S

Call for availability

Kit Gas Conversion NA to LP - MT125

Part # 461063

Call for availability

Rodent Resistant Air Orifice Protection Cap

Part # 475265

Call for availability

Rodent Resistant Gas Pipe Escutcheon

Part # 476107Z

Call for availability

Heater Display Cover

Part # 42002-0035Z

Call for availability

Igniter Bracket

Part # 42001-0030S

Call for availability

Igniter Gasket

Part # 42001-0066S

Call for availability

High Limit Switch

Part # 42001-0063S

$47.94$59.99In Stock

Thermistor

Part # 42001-0053S

$58.94$79.99In Stock

Terminal Board

Part # 42001-0056S

Call for availability

Fireman’s Switch Fuse (1.25A, 1-1/4 in.)

Part # 32850-0099Z

Call for availability

Transformer, 115/230V

Part # 42001-0107Z

Call for availability

Air Flow Switch

Part # 42001-0061S

$99.94$149.99In Stock

Heater, Top

Part # 42002-0034Z

Call for availability

Stack Flue Sensor

Part # 42002-0024S

$94.94$123.99In Stock

Heater Wiring Harness -115/230V

Part # 461107

Call for availability

120/240 Volt Plug Kit

Part # 42001-0105S

Call for availability

Pro Service Package - Electrical System Parts (Includes items in a reusable hardcase, #3,

Part # 461101

Call for availability

Rodent Resistant Exhaust Insert

Part # 476150Z

Call for availability

Rodent Resistant Manifold Insert

Part # 462037Z

Call for availability

Interactive exploded-view parts diagram for the Pentair MasterTemp Heater. Switch between the Water System, Burner System, Electrical System views, then click any numbered part to see the part number, price and stock, or call us and we will find it for you.
