Raypak Digital Heater Bypass Valve | 016194F
Raypak
SKU: 016194F
Raypak 016194F Bypass Valve Kit
Part Number: 016194F
Description
A genuine replacement bypass valve kit designed for select Raypak pool and spa heaters. It regulates water flow through the heat exchanger to maintain efficient operation and protect the heater from improper circulation.
Compatibility & Fitment
- Compatible with Raypak heater models: 105A, 185/185A, 206A, 266A, 336A, 405/405A, 406A, 407A and others using the same bypass valve assembly.
- Ideal when the existing bypass valve is leaking, stuck, cracked or flow regulation is inconsistent.
- Direct replacement for heaters specifying part number 016194F.
Features & Specifications
- Complete kit: bypass valve body, internal spring, seals and mounting hardware.
- Precision construction to match OEM dimensions and performance for correct fit and reliable operation.
- Material suited for pool water, chemical exposure and consistent temperature cycling.
Installation Notes
Shut off the heater’s power and gas supply. Drain or bypass as required to relieve system pressure and isolate the valve location. Remove the old bypass assembly, clean threads and sealing surfaces, install the new kit components, torque as recommended, restore water flow, then power the heater and verify proper operation with no leaks and correct temperature control.
Maintenance Tip
Inspect the bypass valve annually for signs of corrosion, sticking or leakage. Replace if flow regulation falters or the valve body shows any damage to maintain safe and efficient heater performance.
