Pentair IntelliBrite Architectural Series 12V Pool Light Replacement Parts

Pentair

Pentair IntelliBrite Architectural Series 12V Pool Light Replacement Parts

Fits models:IntelliBrite Architectural 12V PoolWhiteWarm White / TurtleColor

  • Genuine PentairOEM factory parts
  • Fast ShippingFrom AZ & NV
  • 5 Local StoresPhoenix · Las Vegas
  • Expert HelpReal pool pros
Shop the complete light

Exploded View

Tap a number to see the part, price and stock.

Pentair Pentair IntelliBrite Architectural Series 12V Pool Light Replacement Parts exploded parts diagram

Pick a part

Click any number on the diagram, or choose from the parts list below.

Know the part number? Use the search in the list.

Common Problems

Show the parts that usually fix it.

Replacement Parts (9)

Pilot Screw

Part # 79104800Z

+1 more option

$7.94$12.99In Stock

Lens Kit

Part # 602168

Call for availability

Gasket

Part # 620400z

Call for availability

LED Board Kit

Part # 618091z / 618090z / 618092z / 618137z / 618135z / 618136z

Call for availability

Fuse Assembly

Part # 618085

Call for availability

White Light Assembly, 300W, 30 ft. (9.2 m)

Part # 602143

Call for availability

White Light Assembly, 300W, 50 ft. (15.2 m)

Part # 602144

Call for availability

White Light Assembly, 300W, 150 ft. (45.7 m)

Part # 602146

Call for availability

White Light Assembly, 500W, 30 ft. (9.2 m)

Part # 602139

Call for availability

White Light Assembly, 500W, 150 ft. (45.7 m)

Part # 602142

Call for availability

Warm White / Turtle Light Assembly, 30 ft. (9.2 m)

Part # 602147

Call for availability

Warm White / Turtle Light Assembly, 50 ft. (15.2 m)

Part # 602148

Call for availability

Warm White / Turtle Light Assembly, 150 ft. (45.7 m)

Part # 602150

Call for availability

Warm White / Turtle Light Assembly (Turtle), 150 ft. (45.7 m)

Part # 602236

Call for availability

Color Light Assembly, 30 ft. (9.2 m)

Part # 602151

Call for availability

Color Light Assembly, 150 ft. (45.7 m)

Part # 602154

Call for availability

Interactive exploded-view parts diagram for the Pentair IntelliBrite Architectural Series 12V Pool Light. Click any numbered part to see the part number, price and stock, or call us and we will find it for you.
