Hayward Universal H-Series Low NOx Heater Replacement Parts

Fits models:H150FDH200FDH250FDH300FDH350FDH400FDH500FD

  • Genuine HaywardOEM factory parts
  • Fast ShippingFrom AZ & NV
  • 5 Local StoresPhoenix · Las Vegas
  • Expert HelpReal pool pros
Shop the complete heater

Exploded View

Tap a number to see the part, price and stock.

Hayward Hayward Universal H-Series Low NOx Heater Replacement Parts exploded parts diagram

Pick a part

Click any number on the diagram, or choose from the parts list below.

Know the part number? Use the search in the list.

Common Problems

Show the parts that usually fix it.

Replacement Parts (22)

Jacket Top

Part # FDXLJKT11501 / FDXLJKT1201 / FDXLJKT1251 / FDXLJKT1301 / FDXLJKT13501 / FDXLJKT1401 / FDXLJKT1501

Call for availability

Front Access Door Assembly

Part # FDXLFAD11501 / FDXLFAD1201 / FDXLFAD1251 / FDXLFAD1301 / FDXLFAD13501 / FDXLFAD1401 / FDXLFAD1501

Call for availability

Rear Access Door Assembly

Part # FDXLRAD1151 / FDXLRAD1201 / FDXLRAD1251 / FDXLRAD1301 / FDXLRAD13501 / FDXLRAD1401 / FDXLRAD1501

Call for availability

Top Front Panel

Part # FDXLTFP1150 / FDXLTFP1201 / FDXLTFP1251 / FDXLTFP1301 / FDXLTFP13501 / FDXLTFP1401

Call for availability

End Cap Panels

Part # FDXLBEC1930

Call for availability

Right Side Trim Panels

Part # FDXLRTP1930

Call for availability

Left Side Trim Panels

Part # FDXLLTP1930

Call for availability

Base Leg

Part # FDXLPBL1930

Call for availability

Flue Collector Side Panel with Temperature Limit

Part # FDXLFCS1930

Call for availability

Rain Guard Assembly

Part # FDXLRGK1151 / FDXLRGK1201 / FDXLRGK1251 / FDXLRGK1351 / FDXLRGK1401 / FDXLRGK1501

Call for availability

Igniter Access Cover

Part # FDXLIAC1930

Call for availability

Gas Manifold / Field Gas Conversion Kit

Part # FDXLGCKW150PN / FDXLGCKW200PN / FDXLGCKW250PN / FDXLGCKW300PN / FDXLGCKW350PN / FDXLGCKW400PN / FDXLGCK1500PN / FDXLGCKW150NP / FDXLGCKW200NP / FDXLGCKW250NP / FDXLGCKW300NP / FDXLGCKW350NP / FDXLGCKW400NP / FDXLGCK1500NP

Call for availability

Blower Inlet Baffle (0-2000 ft. Elevation)

Part # FDXLBBN150 / FDXLBBN200 / FDXLBBN250 / FDXLBBN300 / FDXLBBN350 / FDXLBBN400 / FDXLBBN500

Call for availability

Combustion Blower

Part # FDXLBWR1930

$246.94$299.99In Stock

Ignitor

Part # FDXLIGN1930

$78.15$119.99In Stock

Flame Sensor

Part # IDXLFLS1930

$62.99$79.99In Stock

Transformer

Part # IDXL2TRF1930

$129.99$149.99In Stock

Gasket, CC Front/Air Box

Part # FDXLGSK1934

Call for availability

Water Pressure Switch

Part # FDXLWPS1931

Call for availability

Header Hardware Kit

Part # FDXLHDW1930

Call for availability

3/4" Brass Plug

Part # CHXPLG1930

Call for availability

Drain Plug with Gasket

Part # SPX400FG

Call for availability

High Limit Kit

Part # FDXLHLI1930

$58.75$69.99In Stock

Header Cartridge Retaining Nut

Part # FDXLCRN1930

Call for availability

Header Mounting Base Kit

Part # FDXLHMB1930

Call for availability

Heat Exchanger Assembly

Part # FDXLHXA1150

+4 more options

$1,099.99$1,199.99In Stock

Burner Orifice Kit, Natural

Part # FDXLBON1930 / FDXLBON1500

Call for availability

Burner Orifice Kit, Propane

Part # FDXLBOP1390 / FDXLBOP1500

Call for availability

Gas Conversion Kit, Nat To LP

Part # FDXLCNK0001

Call for availability

Gas Conversion Kit, LP To Nat

Part # FDXLCNK0002

Call for availability

Tie-Down Kit

Part # FDXLTDK1930

Call for availability

Burner (Qty. 8)

Part # FDXLBRN1930

Call for availability

Burner (Qty. 1)

Part # FDXLBRN1931

Call for availability

Insulation, Return Side Tube Sheet

Part # FDXLGSK1934

Call for availability

Wiring Harness Kit, Complete

Part # FDXLWHA1931

Call for availability

Fuse Kit, 3.0 A, for Field Wiring Panel (Qty 10)

Part # FDXLFSKF30

Call for availability

Fuse Kit, 3.0 A, for Ignition Control Board (Qty 10)

Part # FDXLFSKC30

Call for availability

High Altitude Conversion Kit, 2,000-10,000 ft. Elevation

Part # FDXLHAK1931

Call for availability

Indoor Vent 4" Dia Adapter Kit, Pos-Press Cat III (Horz/Vert)

Part # UHXPOSHZ12504

Call for availability

Heatfab SS 4" Dia Adapter

Part # UHXHFA004

Call for availability

Duravent SS 4" Adapter

Part # UHXDVA004

Call for availability

Indoor Vent 6" Dia Adapter Kit, Pos-Press Cat III (Horz/Vert)

Part # UHXPOSHZ11506 / UHXPOSHZ12006 / UHXPOSHZ12506 / UHXPOSHZ14006 / UHXPOSHZ15006

Call for availability

Heatfab SS 6" Dia Adapter

Part # UHXHFA006

Call for availability

Duravent SS 6" Adapter

Part # UHXDVA006

Call for availability

Indoor Vent 8" Dia Adapter Kit, Pos-Press Cat III (Horz/Vert)

Part # UHXPOSHZ13008 / UHXPOSHZ13508 / UHXPOSHZ14008

Call for availability

Interactive exploded-view parts diagram for Hayward Universal H-Series Low NOx heaters (H150FD, H200FD, H250FD, H300FD, H350FD, H400FD, H500FD). Click any numbered part to see the part number, price and stock. Common replacements include the igniter, flame sensor, ignition control, water pressure switch, thermistor, headers and heat exchangers. Not sure which part you need? Call us or bring the old part into any of our stores and we'll match it.
