Hayward PoolVac XL Replacement Parts

Hayward

Hayward PoolVac XL Replacement Parts

Fits models:W32025ADCW32025ADV2025ADC2025ADV

  • Genuine HaywardOEM factory parts
  • Fast ShippingFrom AZ & NV
  • 5 Local StoresPhoenix · Las Vegas
  • Expert HelpReal pool pros
Shop the complete cleaner

Exploded View

Tap a number to see the part, price and stock.

Hayward Hayward PoolVac XL Replacement Parts exploded parts diagram

Pick a part

Click any number on the diagram, or choose from the parts list below.

Know the part number? Use the search in the list.

Common Problems

Show the parts that usually fix it.

Replacement Parts (24)

PoolVac XL Skirt Assembly

Part # AXVU015

Call for availability

PoolVac XL Handle Assembly

Part # AXVU019

Call for availability

PoolVac XL Cover Assembly

Part # AXVU018

Call for availability

Inter Gear

Part # AXV301

$13.94$22.99In Stock

Spindle Gear Screw

Part # AXV068

Call for availability

Cone Spindle Gear

Part # AXV303

Call for availability

Medium Turbine

Part # AXV062C

$19.94$34.99In Stock

Screen Kit

Part # AXVU009

Call for availability

Float Kit

Part # AXV054FH

$24.48$30.95Out of stock

Lower Body

Part # AXV050CWH

$66.94$78.99In Stock

Flap Adjuster

Part # AXV031B

Call for availability

Open Lower Body

Part # AXV230DWH

$39.94$49.99In Stock

Pod Screw Kit

Part # AXV417WHP

$42.99$59.99In Stock

Wing Kit

Part # AXV604WHP

$15.94$19.99In Stock

Shoes Vinyl (4 pack)

Part # AXV413P

+1 more option

$18.94$29.99In Stock

Captive Screw with Clip

Part # AXV314P

Call for availability

Hayward PoolVac XL suction-side pool cleaner parts, matched to the official Hayward parts diagram (3 views). Pick a view, then click any number to see the part, price and stock. Fits models W32025ADC, W32025ADV. Not sure what you need? Call us or bring the part into any of our stores and we'll match it.
