Hayward Flanged Elbow Assembly | ECX4220A
Hayward Products
SKU: ECX4220A
Hayward ECX4220A Flanged Elbow Assembly with Check Valve
Part Number: ECX4220A
Description
A replacement flanged-elbow assembly including integrated one-way check valve designed for use on select Hayward D.E. filter systems. Provides reliable flow control and back-flow protection.
Compatibility & Fitment
- Fits Hayward Perflex EC65/EC75 and similar D.E. filters needing this elbow/check-valve configuration.
- Use when the original elbow is cracked, leaking, the check valve has failed or the part is missing.
- Direct replacement for systems listing part number ECX4220A.
Features & Specifications
- Elbow configuration: flanged connection to filter tank port.
- Includes integrated check valve to prevent reverse flow during service or backwash.
- Machined fitting constructed for pool water use and reliable sealing under pressure.
- Weight: approximately 3.7 lbs (for shipping spec).
Installation Notes
Turn off the pump and relieve system pressure. Drain or backwash the filter as needed. Remove the old elbow assembly and inspect the filter tank flange, gasket surface, and threads. Confirm all sealing surfaces are clean. Install the new ECX4220A assembly, ensure proper torque on flange bolts, prime and restart the system. Check for proper flow and no leaks.
Maintenance Tip
Inspect the elbow assembly and check-valve annually during service. Replace if you observe cracks, leaks, difficulty in valve operation, or signs of back-flow to maintain optimal filter performance and longevity.
